HK-F10/F13/F15
Agile quadcopter platforms for high-performance missions
Compact power, precision control, and modular adaptability.
The HK-F Series is a family of lightweight, high-speed multirotor UAVs designed for versatile deployment and customizable performance. Available in 10-inch, 13-inch, and 15-inch configurations, the series balances endurance, payload, and portability to suit diverse mission requirements. Each model integrates a customizable flight control system, high-efficiency brushless motors, and modular camera and transmission options, enabling precise real-time aerial intelligence. Built for performance and reliability, the HK-F Series offers exceptional acceleration, stability, and control response for professional and tactical operations.
HK-F Series
FPV quadcopter strike & reconnaissance platforms · F10 · F13 · F15 · 10 to 15 inch variants
F10 Size
380 × 310 × 60 mm
F10 Weight
940 g
F10 Flight Control
F40565A ESC
F10 Electrical Machinery
3115 900KV
F10 Propeller
10X5X3
F10 Battery
6S 8000mAh
F10 Rated Load
2.5 kg
F10 Max Load
3 kg
F10 No-load Endurance
38 min
F10 Hover Time
11 min
F10 Max Speed
140 km/h
F10 Image Transmission
10 km
F13 Size
445 × 445 × 30 mm
F13 Weight
1500 g
F13 Flight Control
F405 80A ESC
F13 Electrical Machinery
4312 508KV
F13 Propeller
13X10X3
F13 Battery
6S 12000mAh
F13 Rated Load
4 kg
F13 Max Load
5 kg
F13 No-load Endurance
40 min
F13 Hover Time
10 min
F13 Max Speed
150 km/h
F13 Image Transmission
15 km
F15 Size
500 × 500 × 30 mm
F15 Weight
2000 g
F15 Flight Control
F405100A ESC
F15 Electrical Machinery
4315 360KV
F15 Propeller
15X7X3
F15 Battery
8S 16000mAh / 2.6 kg
F15 Rated Load
7 kg
F15 Max Load
8 kg
F15 No-load Endurance
60 min
F15 Hover Time
10 min
F15 Max Speed
170 km/h
F15 Image Transmission
15 km
Camera (all)
RATEL2 (customizable)
Receiver (all)
ELRS915 (customizable)
Payload Options
Camera: RATEL2 (customizable) · AI tracking module · Full-colour night vision · IR camera · Visible+IR dual light camera
Accessories: LNB · Fiber optic module · Battery · Charger · FPV glasses (5.8GHz, built-in DVR) · Display screen
Accessories: LNB · Fiber optic module · Battery · Charger · FPV glasses (5.8GHz, built-in DVR) · Display screen
Use Cases
- Close-range FPV reconnaissance and target observation
- High-speed payload delivery in confined or complex environments
- Rapid response operations requiring compact quad configuration
- Training and FPV pilot certification programmes
- Multi-role missions with swappable camera and sensor payloads
Key Features
- Three size variants — F10, F13 and F15 — covering 3kg to 8kg max payload
- F15 delivers 60-minute no-load endurance with 170km/h maximum speed
- 15km image transmission range on F13 and F15 variants
- High-speed quadcopter design optimised for agility and low drag
- AI tracking module option for autonomous target following
- Fiber optic module available for EM-hardened data links
